Interface Features:

User definable pages (each page can be draw using Flymaster Instrument Manager, and include a number of elements only limited by space).	8 page sets
Configurable graphical elements (depending of the element several parameters can be set by the user ex. Size, Border, Color, ...)	15
Configurable data field elements (User can change size, border, title, Font, Color, ...)	85
Page Trigger Events (page switches automatically if a specific event occurs)	Airspace warning Entering thermal Transition (leaving thermal) Arriving at turn point Start opened Power up
Interface language	English
Configurable voice alerts	Airspace Turn point complete Start opened Goal Possible Distances Countdown time

Variometer/Altimeter Features:

Buzzer/near thermal sound
Ultra sensitive Variometer with 10 readings per second and 10 cm resolution
Configurable vario digital filter and integration values
Fully configurable Vario Sound (frequency, increments, frequency/vertical speed relation,….)
Adjustable Sound Levels
Automatic mute, keeps vario silent until takeoff
Altitude adjustment using QNH
Automatic altitude adjustment from GPS
2 independent altimeters

Memory Features:

3D Airspace:

The map offers an intuitive visualization of restricted areas, ensuring easy identification and awareness of prohibited zones.
Adjustable voice warning of vertical distance to a restricted area
Adjustable voice warning of horizontal distance to a restricted area
Display of shortest vertical, and horizontal distance to restricted area
Restricted area voice alarms (Altitude imminent, Position imminent, Violation, …)
Critical Airspace page (displays information about areas that are closer than a defined distance)
Airspaces browser
Worldwide Airspace database

Maps:

Cross Country Features:

Exclusive Thermal Ball indicator
Several specific data fields like distance to take off, current and average glide ratio, average speed, etc.
Distance to last thermal indexed with altitude
Goto waypoint
Multiple waypoint route
Wind Speed and Direction (GPS based calculations)
Automatic altitude gain profiler
Nearby Landings (displays required glide ratio and distance to all the landings which can be reached)

Competition Features:

Live Tracking:

Flight data can be efficiently uploaded to various repositories, such as the Leonardo XC server, XContest, and DHV, utilizing the GSM network.
Automatic almost real time flight data sending to a remote live tracking server through GSM network. (compatible with several servers like Flymaster, LiveTrack24, DHV, etc)
On demand sending of predefined messages to a server (eg. Need Assistance, Need Retrieval, etc)
Effortlessly receive data from a remote server, including alarm messages, task definitions, and more, through automated processes.
Optimized LTE-M/GPRS data usage is minimal, with an average requirement of only 25KB per flight/hour, assuming uninterrupted communication.

Interfacing:

FlyMaster GPS
